Foam PVC Sheet

(AKA Closed-cell PVC foamboard)

Foam_PVC_Display

Foam PVC Sheet is a light weight extruded sheet made with a closed cell structure. This closed cell foam makes it virtually impermeable to air; immune to sunlight, rain and has a R-value for construction. In addition due to its closed cell structure it is very light and easily machinable. It is self-extinguishing and will not decay.

There are many brand names of foam PVC… like Sintra, Celtec, Simopor, and Komatex. For additional information on PVC read our blog.



Still not sure PVC is the proper material for your application, consult our free Plastic Materials Selection Guide

Why use Foam PVC in your applications:

  • Lightweight
  • Highly resistant to moisture and some chemicals
  • Used in screen printing, advertising, and labeling
  • Used for POP panels
  • Easily Machinable
  • Matte surface accepts most inks, vinyls and paints

This materials is…versatile for multiple applications. Machines well and has very good impact strength.

  • R- Value (insulation) for construction
  • Very Low Moisture absorption
  • Has Low Density
  • Excellent physical properties
  • Bonds well to adhesives
  • Low flammability (UL-94 VO flame rating) Komatex

Still not sure foam PVC is the proper material for your application, consult our free Plastic Materials Selection Guide.

Applications – Frequently used in:Foam PVC_Assorted_Colors

  • Marine Industry
  • Aerospace Industry
  • Building and Construction
  • Wind Energy Industry

Still not sure foam PVC is the proper material for your application, consult our free Plastic Materials Selection Guide. These Properties are for evaluation purposes only. This information is not to be construed as a warranty, guarantee or assurance that you may achieve the same results. Materials made from different resin types, manufacturing techniques and manufacturers will react differently. The information should be used to compare against other materials only, and each user should make his own tests to determine suitability. No warranty as to this materials suitability are either expressed or implied.

Materials Available As

Sheet:

.118″ , .236″ and .500″ .118″ , .236″ and .500″ Also available: White and Black. Other colors available on special order.

Special Formulations:

Custom sizes, formulations, profiles or colors. These Properties are for evaluation purposes only. This information is not to be construed as a warranty, guarantee or assurance that you may achieve the same results. Materials made from different resin types, manufacturing techniques and manufacturers will react differently. The information should be used to compare against other materials only, and each user should make his own tests to determine suitability. No warranty as to this materials suitability are either expressed or implied.

Typical Material Properties:

General Property ASTM Test Typical Value
Specific Gravity D792 1.37
Tensile Strength Yield D638 7,400
Water Absorption 24hr. (%) D570 0.032
Izod Impact – Notched D256 1 – 3
Hardness – Rockwell D785 R116
Deflection Temp @ 264psi D648 165
UL – Flammability (.032″ thickness) UL 94 V-0
Co. Thermal Expansion D696 2.95X10-5

“I use foam PVC to screen print signs. The matte makes my work finish look amazing” – Jorge M. “This material is one of those that you can’t quantify the uses because there are so many choices.” – Larry T.

Foam_PVC.118Available in White and Black .118" thick
Foam_PVC.236Available in White .236" thick
Foam_PVC.500Available in White .500" thick
